6 1/2″ M1365FG M433

Category:

6″— 6 1/2″

Matrix Body PDC Bit

Send Email:

Product details

Nomenclature of RUISHI Matrix Body PDC Bit Model

S/M 19 5 5 X
Matrix Body PDC Bit Cutter Size
19:
diameter 19mm
16:
diameter 16mm
13:
diameter 13mm
Blade Count
3、4、5、6...
Formation
from soft to hard
1-7
Design Characters
J/A J Series
X Sprial Gauge
C Sidetracking Bit
Q Core Bit
B Bi-center Bit
F Row Cutters
G Advanced Cutters



BITS SPECIFICATIONS

Size 8 1/2"
Number of blade 6
Primary Cutter Size(mm) 13
Nozzle Qty 6
Gauge Length 2"-3.5"
Connection 3-1/2"API REG



RECOMMENDED PARAMETERS

Rotary Speed(rpm) 60-250
Weight On Bit(KN) 10-100
Flow Rate(lps) 25-30



Trait:double rows、spiral 6 blades、6 water holes



Suitable for medium soft formations

   Limestone、claystone、shale…



The design of spiral blades with double rows

 Optimize the tooth distribution structure、increase the attack ability of the bit



Add shock absorption column at the auxiliary tooth position

   Reduce the vibration of drill bit during drilling、effectively control the cutting depth of cutting teeth、protect the cutting teeth to improve the life of the bit



Design of short outer cone

   Improve the directional drilling ability of bit in directional well



Optimize water circulation system

   Optimize water conservancy structure、increase the chips removal and mud bags prevention
