6″ M1652C M223

Category:

Matrix Body PDC Bit

6″— 6 1/2″

Send Email:

Product details

Nomenclature of RUISHI Matrix Body PDC Bit Model

S/M 19 5 5 X

Matrix Body  PDC Bit

Cutter Size
19:
diameter 19mm
16:
diameter 16mm
13:
diameter 13mm
Blade Count
3、4、5、6...
Formation
from soft to hard
1-7

Design Characters
J/A J Series
X Sprial Gauge
C Sidetracking Bit
Q Core Bit
B Bi-center Bit
F Row Cutters
G Advanced Cutters



BITS SPECIFICATIONS

Size 6"
Number of blade 5
Primary Cutter Size(mm) 16
Nozzle Qty 5
Gauge Length 2"-3.5"
Connection 4-1/2"API REG



RECOMMENDED PARAMETERS

Rotary Speed(rpm) 60-250
Weight On Bit(KN) 10-100
Flow Rate(lps) 25-36



Trait:single row、5 blades、5 water holes



Suitable for medium soft formations

   Limestone、claystone、shale…



Sintered with high-quality tungsten carbide material

   Excellent erosion resistance



The structure of the middle parabolic shape

   Maximize the abrasion resistance and stability of bit
   Increase the mechanical penetration rate、stability、service life of the bit



Optimize water conservancy structure

   The design of bottom hole fluidization is conducive to the chip removal and mud bags prevention



Reasonable configuration of high-quality PDC cutters

   Optimize the tooth distribution structure、increase the attack ability and wear resistance of the bit
