8 1/2″ M332 PDC CORE BIT

Category:

Core and combined bit

Send Email:

Product details

Nomenclature of RUlSHI Core and combined bit Model

S 19 5 5 X
S:
Steel Body PDC Bit
M:
Matrix Body PDC Bit
Cutter Size
19:
diameter 19mm
16:
diameter 16mm
13:
diameter 13mm
Blade Count
3、4、5、6...
Formation
from soft to hard
1-7
Design Characters
J/A J Series
X Sprial Gauge
C Sidetracking Bit
Q Core Bit
B Bi-center Bit
F Row Cutters
G Advanced Cutters



BITS SPECIFICATIONS

Size 8 1/2"
Number of blade 12
Primary Cutter Size(mm) 8
TFA(in2 0.5-1.2
Gauge Length 1.5"
Connection

CHUAN8-3CBS
CHUAN8-4CBS



RECOMMENDED PARAMETERS

Rotary Speed(rpm) 40-150
Weight On Bit(KN) 23-70
Flow Rate(lps) 11-20



Trait:curved crown、12 blades、core



Suitable for coring in soft to medium-hard formations with abrasiveness

   Soft shale、limestone、sandstone…



Arc-shaped crown design

   Blade arrangement standard PDC cutters、reatly improve the cutting footage ability of the bit



Inner and outer diameter of natural diamond、Design of the balance of the binding force of the tooth arrangement

   Increase the wear resistance、stability and life of the gauge、Improve bit coring rate



The water channel optimization design

   Fully clean and cool the bit
